Product model:Small environment-friendly boiler

Release time:2017-05-17 Browse number:200people information sources:

Large coal-fired boiler

Remarkable energy-saving effect and high heat efficiency;

Mechanized slag removal and easy to operate;

Short installation period, quick start and firing;

Easy to install and move, saving investment of infrastructure construction


tel:024-23712222


Product features

The small environment-friendly boiler is a type of efficient, multifunctional, energy-saving and innovative atmospheric-pressure product reducing environmental pollution. It is used conveniently, saving labor and hour and integrating boiled water supply, rice steaming and bathing (we also provide the type only supplying boiler water). The automatic grate is treated without dirt, which is initiated in the industry. In this case, its safe operation, long service life and stable performance can be ensured. Therefore, the product is applicable to schools having boarders as well as organs, troops and enterprise and public institutions with family member courtyard.


Application scope

Product features

1. Safe use under atmospheric pressure, easy operation, full automatic control by microcomputer, automatic water adding, automatic control of water outlet temperature, automatic control of heat supply temperature, and possible safe operation by an ordinary person.


2. Energy saving and high efficiency; we adopt high-tech means and add an oxygen inlet on the boiler body to overcome the insufficient combustion of traditional type due to oxygen deficit during combustion in the hearth. Through filling oxygen into the boiler, the combustion become more sufficient and the heat energy utilization rate is high.

3. By applying the circulating combustion technology, the heating area in the furnace is increased and the service life of boiler is also enhanced.

4. The circulating combustion is adopted at the oxygen inlet to reach the dust-free and environment protection effect.

Smart control of indoor temperature Smart control of hot water circulation Smart fire preservation to maintain combustion Automatic alarm of abnormality

Quick temperature rise and stable thermal power Colorless smoke discharge and environmental protection No chimney required and easy installation Easy operation and labor and time saving

Configuration and parameters

Model Power Heat supply area( m²) Operating pressure( Mpa) Heat efficiency(%) onsumption( kg/h) Rated water outlet/ return temperature (°C) Water capacity of boiler (kg) Rated voltage( V/kw)
Parameter MW Kcal/h

CZML-0.058

0.058

5×104

400-600

Atmospheric pressure

≥75

10-12

85/60

260

220/0.31

CZML-0.12

0.12

10×104

900-1200

Atmospheric pressure

≥75

22-24

85/60

360

220/0.43

CZML-0.24

0.24

20×104

1700-2100

Atmospheric pressure

≥75

48-52

85/60

580

220/0.93

CZML-0.35

0.35

30×104

2400-3000

Atmospheric pressure

≥75

70-76

85/60

830

220/0.93

CZML-0.48

0.48

40×104

3800-4000

Atmospheric pressure

≥75

120-125

85/60

1080

220/1.68

CZML-0.7

0.7

60×104

5500-5800

Atmospheric pressure

≥75

132-144

85/60

1380

220/1.68

CZML-1.4

1.4

120×104

11000-12000

Atmospheric pressure

≥76

300

85/60

3500

380/-
